Gewindemesser 60°

Bezeichnung	BP (mm)	P max	R (mm)	ε (°)	Schneidrichtung	Einheit
0/1-K60-E-KOB	3.5	3.5 mm	0.3	60	R	(Stück)
0/1-K60-E-SUPER-KOB	4.5	4.5 mm	0.35	60	R	(Stück)
0/1-K60-E-TIN	3.5	3.5 mm	0.3	60	R	(Stück)
0/1-K60-N-K10	3	3 mm	0.07	60	R	(Stück)
0/1-K60-N-KOB	2.5	2.5 mm	0.07	60	R	(Stück)
0/1-K60-N-P30	3	3 mm	0.07	60	R	(Stück)
0/1-K60-N-TIN	2.5	2.5 mm	0.07	60	R	(Stück)
0/1-L60-N-K10	3	3 mm	0.07	60	L	(Stück)
0/1-L60-N-KOB	2.5	2.5 mm	0.07	60	L	(Stück)
0/1-L60-N-P30	3	3 mm	0.07	60	L	(Stück)
0/1-L60-N-TIN	2.5	2.5 mm	0.07	60	L	(Stück)
2-K60-E-KOB	4.5	4.5 mm	0.35	60	R	(Stück)
2-K60-E-SUPER-KOB	6	6 mm	0.5	60	R	(Stück)
2-K60-E-TIN	4.5	4.5 mm	0.35	60	R	(Stück)
2-K60-N-K10	3.5	3.5 mm	0.1	60	R	(Stück)
2-K60-N-KOB	3	3 mm	0.1	60	R	(Stück)
2-K60-N-P30	3.5	3.5 mm	0.1	60	R	(Stück)
2-K60-N-TIN	3	3 mm	0.1	60	R	(Stück)
2-L60-N-K10	3.5	3.5 mm	0.1	60	L	(Stück)
2-L60-N-KOB	3	3 mm	0.1	60	L	(Stück)
2-L60-N-P30	3.5	3.5 mm	0.1	60	L	(Stück)
2-L60-N-TIN	3	3 mm	0.1	60	L	(Stück)
3-K60-E-KOB	5.5	5.5 mm	0.45	60	R	(Stück)
3-K60-E-SUPER-KOB	7.5	7.5 mm	0.75	60	R	(Stück)
3-K60-E-TIN	5.5	5.5 mm	0.45	60	R	(Stück)
3-K60-N-K10	4.5	4.5 mm	0.12	60	R	(Stück)
3-K60-N-KOB	3.5	3.5 mm	0.12	60	R	(Stück)
3-K60-N-P30	4.5	4.5 mm	0.12	60	R	(Stück)
3-K60-N-TIN	3.5	3.5 mm	0.12	60	R	(Stück)
3-L60-N-K10	4.5	4.5 mm	0.12	60	L	(Stück)
